Steel Pile Solar Panel Ground Mounting Systems Rapid Installation
Steel pile mounting system is designed and engineered for each
customer’s site specific conditions to minimize the field
installation labor and require no field welding, drilling.By using
pile driving machine hydraulically push galvanized steel posts into
the ground to the required depth without using poured concrete to
support a steel racking system, it just takes some seconds to
finish a piling pole.
Short Description:
► Min.Order Quantity: 5 Set
► Max Building Height: 20m
► Install Angle: 0-60 degree
► Supply Ability: 50000 Set/Sets per Month
► Payment Terms: L/C,D/A,D/P,T/T
► Port : Tianjin,Shanghai,Qingdao
Product Parameter :
Type: Ground solar mounting
Material: Q235B,Q345B,Component Aluminum Alloy & Stainless
Steel etc, Customized upon requirement.
Structural materials: Aluminum Alloy, Hot-Galvanized Steel,
Stainless Steel
Module Orientation: Portrait or landscape
Treatment: Anodized, Galvanized
Max Building Height: 20m
Span: As required
Column: Hot rolled plain steel
Beam: C steel
Installation Site: Open Field/ Ground / Earth / Concrete Ground
Components Parts: Leg Cap; Front/Rear Leg; Fix Ring; Cross Pipe; U
Connector; Rail; Mid Clamp; End Clamp;Enforcement Pipe
| Application | Mountain, Plain, Highland, Desert |
| Installation Angle | 5~40° |
| Ground Clearance | ≥ 0.15m |
| Wind load | 130mph(60m/s) |
| Snow Load | 30psf(1.4kN/m2) |
| Module type | Any type of PV moduels |
| Surface treatment | Hot Dip Galvanizing & Anodized |
| Applicable Module | Framed or Frameless |
| Color | Natural or Customized |
| Warranty | 10 years warranty and 25 years duration |
| Array Layout | According to the actual situation |
Product feature:
1. Professional Design
Products were designed by the experienced designers which have the
systematic design, stable structure, mature technology, can reduce
the difficulty of the installation on the most conditions.
2. Easy Installation
The innovative rail and rail nut have greatly simplified the
installation of solar panels. The system can be installed with a
single Hexagon Key and standard tool kit. The rail nut and unique
rail extension method allow greatly reduced installation times.
3. Safety
The racking systems can stand up to the extreme weather condition.
The main support components have also been tested to guarantee its
structure and load-carrying capacity.
4. Super quality
All products are made by experienced skilled staffs to operate
quality. With strictly full inspected and controlled by Qc
department.
5. Flexibility
The flexibility of screw foundation-ground screw or concrete
foundation.
Packaging & Delivery:
► Port: Tianjin, Shanghai, Qingdao
► Payment Terms: L/C,D/A,D/P,T/T
Certification:
|
|
